Heavy duty 4 axle flat bed trailer product use: flat bed trailer can transport containers, steel, especially steel mills and steel distribution centers for the transfer of steel coils and plates, etc.
In order to be more suitable for transportation under heavy load and complicated environment, 4 axle flat bed trailer is welded and formed by imported fully automatic tracking submerged arc welding machine. The heavy duty flatbed trailer unique multi-angle structure of longitudinal beam strengthens the bearing capacity and anti-deformation ability of the entire longitudinal beam.
Dangote 4 Axle Flat Bed Trailer Price | Semi Truck Flatbed Trailer for Sale
Dangote 4 Axle Flat Bed Trailer Price | Semi Truck Flatbed Trailer for Sale
Dangote 4 Axle Flat Bed Trailer Price | Semi Truck Flatbed Trailer for Sale
Dangote 4 Axle Flat Bed Trailer Price | Semi Truck Flatbed Trailer for Sale
Dimension(mm): 13900x2500x1587mm
Transport: 20ft, 40ft, 45ft, 48ft container
Loading capacity(ton): ≤60T
Axles: 4 axles, 13T/16T ,FUWA/ BPW
Tire: 16 units, 12.00R22.5 or 315/80R22.5
Rim: 9.00-22.5 or 9.75-22.5
Suspension: Mechanical suspension
Spring Leaf: 90(W)mmx13(Thickness)mmx10 layers or 100mmx12mmx12 (specially intended for overseas markets)
King Pin: JOST brand 2.0 or 3.5 inch (bolted or welded)
Landing Gear: JOST brand D200T or Chinese brand 28tons(double-speed)
Main Beam: Height: 500mm, Upper plate:14mm, Middle plate:8mm, Bottom plate:16mm, Material:Q345B steel
Side Beam: 16mm or 18mm steel channel (material: Q235 steel)
Platform: 3mm-thick checkered plate
Brake Chamber: WABCO RE 6 relay valve; T30/30+T30 spring brake chamber(TKL brand), 45L air tank
Twist Locks: 4,8,12 sets (lifting or screw type)
Valve: WABCO valve (specially intended for oversea market)
ABS: Optional
Light: LED light (specially intended for oversea market)
Voltage: 24V
Socket(Receptacle): 7-pin Socket (for 7 wire harness)
Tool Box: 1m x 0.5m x 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs)
Painting: Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats
